Quectel EC21 Series User Manual

LTE Standard Module Series
EC21_Series_Hardware_Design
75
/ 118
Table 34: EC21-J Conducted RF Receiving Sensitivity
Table 35: EC21-KL Conducted RF Receiving Sensitivity
Frequency Bands
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
8
LTE-FDD B1 (10 MHz) -98.0 dBm -99.5 dBm -100.5 dBm -96.3 dBm
LTE-FDD B3 (10 MHz) -97.0 dBm -97.5 dBm -99.5 dBm -93.3 dBm
LTE-FDD B5 (10 MHz) -98.0 dBm -99.5 dBm -100.5 dBm -94.3 dBm
LTE-FDD B7 (10 MHz) -96.0 dBm -96.0 dBm -98.5 dBm -94.3 dBm
LTE-FDD B8 (10 MHz) -97.0 dBm -99.0 dBm -101.0 dBm -93.3 dBm
Table 36: EC21-AUX Conducted RF Receiving Sensitivity
Frequency Bands
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
8
LTE-FDD B1 (10 MHz) -97.5 dBm -98.7 dBm -100.2 dBm -96.3 dBm
LTE-FDD B3 (10 MHz) -96.5 dBm -97.1 dBm -100.5 dBm -93.3 dBm
LTE-FDD B8 (10 MHz) -98.4 dBm -99.0 dBm -101.2 dBm -93.3 dBm
LTE-FDD B18 (10 MHz) -99.5 dBm -99.0 dBm -101.7 dBm -96.3 dBm
LTE-FDD B19 (10 MHz) -99.2 dBm -99.0 dBm -101.4 dBm -96.3 dBm
LTE-FDD B26 (10 MHz) -99.5 dBm -99.0 dBm -101.5 dBm -93.8 dBm
Frequency Bands
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
8
GSM850 -109.0 dBm - - -102.0 dBm
EGSM900 -109.0 dBm - - -102.0 dBm
DCS1800 -109.0 dBm - - -102.0 dBm
