LTE Standard Module Series
EC21_Series_Hardware_Design
76
/ 118
Table 37: EC21-EUX Conducted RF Receiving Sensitivity
PCS1900 -109.0 dBm - - -102.0 dBm
WCDMA B1 -110.0 dBm -109.5 dBm -112 dBm -106.7 dBm
WCDMA B2 -110.5 dBm - - -104.7 dBm
WCDMA B4 -110.0 dBm -110 dBm -112 dBm -104.7 dBm
WCDMA B5 -111.0 dBm -112 dBm -113 dBm -104.7 dBm
WCDMA B8 -111.0 dBm -112 dBm -113 dBm -103.7 dBm
LTE-FDD B1 (10 MHz) -98.0 dBm -97.7 dBm -101.2 dBm -96.3 dBm
LTE-FDD B2 (10 MHz) -98.5 dBm - - -94.3 dBm
LTE-FDD B3 (10 MHz) -99.0 dBm -98.8 dBm -102.2 dBm -93.3 dBm
LTE-FDD B4 (10 MHz) -97.7 dBm -97.6 dBm -100.2 dBm -96.3 dBm
LTE-FDD B5 (10 MHz) -98.5 dBm -98.2 dBm -101.0 dBm -94.3 dBm
LTE-FDD B7 (10 MHz) -97.7 dBm -97.7 dBm -101.2 dBm -94.3 dBm
LTE-FDD B8 (10 MHz) -99.0 dBm -98.5 dBm -102.2 dBm -93.3 dBm
LTE-FDD B28 (10 MHz) -98.0 dBm -98.7 dBm -101.5 dBm -94.8 dBm
LTE-TDD B40 (10 MHz) -97.5 dBm -98.2 dBm -101.2 dBm -96.3 dBm
Frequency Bands
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
8
EGSM900 -109.0 dBm - - -102.0 dBm
DCS1800 -109.0 dBm - - -102.0 dBm
WCDMA B1 -110.5 dBm - - -106.7 dBm
WCDMA B8 -110.5 dBm - - -103.7 dBm
LTE-FDD B1 (10 MHz) -98.0 dBm -98.0 dBm -101.0 dBm -96.3 dBm
LTE-FDD B3 (10 MHz) -98.5 dBm -98.5 dBm -101.0 dBm -93.3 dBm
