LTE-FDD B28 @ 22.84 dBm 670.0 mA
LTE-FDD B66 @ 22.73 dBm 725.9 mA
GSM
voice call
GSM850 PCL5 @32.57dBm 227.8 mA
EGSM900 PCL5 @33.21dBm 253.8 mA
DCS1800 PCL0 @30.24dBm 168.0 mA
PCS1900 PCL0 @30.33dBm 166.8 mA
WCDMA
voice call
WCDMA B1 @22.93dBm 656.2 mA
WCDMA B2 @22.95dBm 579.8 mA
WCDMA B5 @22.54dBm 589.8 mA
WCDMA B8 @22.47dBm 627.8 mA
Table 40: GNSS Current Consumption of EG91
6.5. RF Output Power
The following table shows the RF output power of EG91 series module.
Table 41: RF Output Power
Frequency Max. Min.
GSM850 33dBm±2dB 5dBm±5dB
Parameter Description Conditions Typ. Unit
I
VBAT
(GNSS)
Searching
(AT+CFUN=0)
Cold start @Passive Antenna 54 mA
Hot Start @Passive Antenna 54 mA
Lost state @Passive Antenna 53 mA
Tracking
(AT+CFUN=0)
Open Sky @Passive Antenna 32 mA
