Quectel EG915U Series User Manual

LTE Standard Module Series
EG915U_Series_Hardware_Design 67 / 91
Table 32: EG915U-EU Current Consumption
DCS1800P CL=7 @ 15.97 dBm
0.3
A
DCS1800P CL=15 @ 0.28 dBm
0.15
A
EG915U-EU
Description
Conditions
Typ.
Unit
OFF state
Power down
43
µA
Sleep state
AT+CFUN=0 (USB disconnected)
1.01
mA
AT+CFUN=0 (USB connected)
2.2
mA
AT+CFUN=4 (USB disconnected)
1.02
mA
AT+CFUN=4 (USB connected)
2.21
mA
EGSM @ DRX = 2 (USB disconnected)
2.09
mA
EGSM @ DRX = 5 (USB disconnected)
1.55
mA
EGSM @ DRX = 5 (USB connected)
2.67
mA
EGSM @ DRX = 9 (USB disconnected)
1.39
mA
DCS @ DRX = 2 (USB disconnected)
2.1
mA
DCS @ DRX = 5 (USB disconnected)
1.5
mA
DCS @ DRX = 5 (USB connected)
2.78
mA
DCS @ DRX = 9 (USB disconnected)
1.36
mA
LTE-FDD @ PF = 32 (USB disconnected)
3.49
mA
LTE-FDD @ PF = 64 (USB disconnected)
2.22
mA
LTE-FDD @ PF = 64 (USB connected)
3.48
mA
LTE-FDD @ PF = 128 (USB disconnected)
1.63
mA
LTE-FDD @ PF = 256 (USB disconnected)
1.34
mA
Idle state
EGSM @ DRX = 5 (USB disconnected)
12.05
mA
