2 Product Overview
EG915U series module is an LTE-FDD, LTE-TDD and GSM wireless communication module, which
provides data connectivity on LTE-FDD, LTE-TDD and GPRS networks. It also provides voice
functionality, Bluetooth and Wi-Fi Scan
1
to meet your specific application demands. Related information
and details are listed in the table below:
Table 2: Brief Introduction of the Module
2.1. Frequency Bands and Functions
Table 2: Wireless Network Type
1
EG915U series support Bluetooth and Wi-Fi Scan functions. Due to the shared antenna interface, the two functions
cannot be used simultaneously. Bluetooth and Wi-Fi Scan functions are optional (both supported or not), please contact
Quectel Technical Support for details.
2
Only EG915U-CN provides LTE-TDD, please consult Quectel Technical Support for details.
Categories
Packaging and pins number
126-pin; LGA
Dimensions
(23.6 ±0.2 ) mm × (19.9 ±0.2 ) mm × (2.4±0.2 )mm
Weight
2.5 ±0.2 g
Wireless network functions
LTE/GSM/Bluetooth/Wi-Fi Scan
1
Variants
EG915U-CN
2
; EG915U-EU; EG915U-LA
Wireless Network
Type
EG915U-CN
EG915U-EU
EG915U-LA
LTE-FDD
B1/B3/B5/B8
B1/B3/B5/B7/B8/B20/B28
B2/B3/B4/B5/B7/B8/B28
/B66
LTE-TDD
B34/B38/B39/B40/B41
-
-
GSM
900/1800 MHz
850/900/1800/1900 MHz
850/900/1800/1900 MHz
Bluetooth and Wi-Fi
Scan
1
2.4 GHz
2.4 GHz
2.4 GHz
