Table 5: Wi-Fi Power Consumption
Condition I
VDD_FEM
I
VBAT
Unit
802.11ah, Tx
@ 915 MHz
1 MHz @ MCS 0 120 58 mA
2 MHz @ MCS 0 114 60 mA
4 MHz @ MCS 0 104 64 mA
8 MHz @ MCS 0 93 72 mA
1 MHz @ MCS 7 72 49 mA
2 MHz @ MCS 7 58 48 mA
4 MHz @ MCS 7 45 49 mA
8 MHz @ MCS 7 35 54 mA
1 MHz @ MCS 10 119 58 mA
802.11ah, Rx
@ 915 MHz
1 MHz @ MCS 0 5 27 mA
2 MHz @ MCS 0 5 29 mA
4 MHz @ MCS 0 5 36 mA
8 MHz @ MCS 0 5 42 mA
1 MHz @ MCS 7 5 29 mA
2 MHz @ MCS 7 5 31 mA
4 MHz @ MCS 7 5 36 mA
8 MHz @ MCS 7 5 43 mA
1 MHz @ MCS 10 5 28 mA
