Quectel LC76G Series User Manual

GNSS Module Series
LC76G_Series_EVB_User_Guide 8 / 33
1 Introduction
This document provides information on the steps needed to evaluate the Quectel LC76G series module
using the Evaluation Board (EVB). The EVB is a convenient tool that allows you to become familiar with
the module.
Specifically, the document is divided into several sections:
 Chapter 2 provides the general overview of EVB kit.
 Chapter 3 describes the EVB user interfaces.
 Chapter 4 describes how to test the module and upgrade the firmware via QGNSS tool.
 Chapter 5 describes the installation of EVB and antenna.
 Chapter 6 describes how to measure power consumption for the module.
 Chapter 7 provides the EVB framework.
 Chapter 8 describes the common problems and troubleshooting.
 Chapter 9 describes the cautions.
 Chapter 10 is an appendix, which summarizes the relevant documents, terms and abbreviations
appearing herein.

Request the software tool QGNSS from Quectel Technical Support (support@quectel.com).
1.1. Special Mark
Table 1: Special Mark
Mark Definition
*
Unless otherwise specified, when an asterisk (*) is used after a function, feature, interface,
pin name, or argument, it indicates that the function, feature, interface, pin, or argument is
under development and currently not supported; and the asterisk (*) after a model indicates
that the sample of the model is currently unavailable.
