5.4. Current Consumption
The values of current consumption are shown as below.
Table 32: The Module Current Consumption
DATA mode, GPRS (4 Rx, 1Tx)
GSM850/EGSM900
1)
DCS1800/PCS1900
2)
217/234
172/170
mA
mA
DATA mode, GPRS (1Rx, 4Tx)
GSM850/EGSM900
1)
DCS1800/PCS1900
2)
458/485
3)
462/439
mA
mA
Peak supply
current (during
transmission
slot)
Maximum power control level
on GSM850 and EGSM900.
1.6
2
A
Condition
Current Consumption
Voice Call
GSM850
@power level #5 <300mA, Typical 223mA
@power level #12, Typical 83mA
@power level #19, Typical 62mA
EGSM900
@power level #5 <300mA, Typical 219mA
@power level #12, Typical 83mA
@power level #19, Typical 63mA
DCS1800
@power level #0 <250mA, Typical 153mA
@power level #7, Typical 73mA
@power level #15, Typical 60mA
PCS1900
@power level #0 <250mA, Typical 151mA
@power level #7, Typical 76mA
@power level #15, Typical 61mA
GPRS Data
NOTE
