Smart Module Series
Smart_EVB_G5_User_Guide 41 / 66
The following figure shows the camera interfaces with cameras assembled.
Figure 21: Camera Interfaces with Cameras Assembled
USB Interfaces
The Smart EVB G5 provides two USB interfaces: a micro-USB interface and a type-C interface.
Table 15: Description of USB Interfaces
⚫ The Type-C interface complies with the USB 3.0 specifications and supports super-speed (5 Gbps)
on USB 3.0, high-speed (480 Mbps) on USB 2.0 and full-speed (12 Mbps) modes. USB Type-C
interface support USB OTG function, and is used for AT command communication, data transmission,
software debugging and firmware upgrade.
⚫ The Micro-USB interface complies with the USB 2.0 specifications and supports high-speed (480
Mbps) on USB 2.0 and full-speed (12 Mbps) modes.
