Quectel UG96 User Manual

HSPA/UMTS/GSM/GPRS Module Series
UG96&UG95&M95 R2.0 Compatible Design
UG96&UG95&M95 R2.0_Compatible_Design 9 / 42
1.
1)
Within operation temperature range, the module is 3GPP compliant.
2.
2)
Within extended temperature range, the module remains the ability to establish and maintain a
voice, SMS, data transmission, emergency call, etc. There is no unrecoverable malfunction. There
are also no effects on radio spectrum and no harm to radio network. Only one or more parameters like
P
out
might reduce in their value and exceed the specified tolerances. When the temperature returns to
normal operating temperature levels, the module will meet 3GPP specifications again.
range:
-40°C ~ +90°C
range:
-40°C ~ +90°C
range:
-40°C ~ +90°C
(U)SIM Interface
1.8V/3.0V (U)SIM
1.8V/3.0V (U)SIM
1.8V/3.0V (U)SIM
UART Interface
Baudrate:
300bps~921600bps
Autobauding:
4800bps~115200bps
Flow control: RTS/CTS
Signal level: 1.8V
Baudrate:
300bps~921600bps
Autobauding:
4800bps~115200bps
Flow control: RTS/CTS
Signal level: 1.8V
Baudrate:
300bps~115200bps
Autobauding:
4800bps~115200bps
Flow control: RTS/CTS
Signal level: 2.8V
USB Interface
USB 2.0 high speed
device interface
USB 2.0 high speed
device interface
Not supported
Analog Audio
Not supported
Not supported
Two analogy input
channels and two
analogy output
channels
Digital Audio
One Pulse Code
Modulation (PCM)
digital interface
One Pulse Code
Modulation (PCM) digital
interface
One Pulse Code
Modulation (PCM)
digital interface
RTC Backup
Vnorm=1.8V
V
I
=1.0V~1.9V
Vnorm=1.8V
V
I
=1.0V~1.9V
V
O
max=3.0V
V
I
=1.5V~3.3V
I2C Interface
Supported
Supported
Not supported
NOTES

Quectel UG96 Specifications

General

Brand	Quectel
Model	UG96
Category	Control Unit
Language	English
