13
5 - Wiring diagram
WINDLASS
CONTACTOR BOX
T6315-12 (12V)
T6315-24 (24V)
FOOT-OPERATED SWITCHES MOD. 900U E 900D
BLACK
BROWN
BLUE
FUSE
4A (12V)
2A (24V)
RRC R02 RECEIVER
POCKET-SIZE RRC P02 PUSH-
BUTTON PANEL RRC H02
PANEL CHAIN-COUNTER
CHC 1203 - QNC CHC
CONTROLS FOR CONTROL
BOARD WCS 820 - WCS
B - WCS 830
CHAIN-COUNTER
PUSH-BUTTON PANEL
CHC 1103
RRC REMOTE RADIO CONTROLS
WCS 830
WINDLASS CONTROL SWITCH
TRANSMITTERS
MULTI-PURPOSE
PUSH-BUTTON
PANEL
HRC 1002
5.1 - Example of connection DP2 P 700W - 1000W / DP3 1500W
with recommended Quick
®
accessories for the operation of the windlass
MOTOR
BROWN BLACK BLUE
L1
L2
L3
L3
L4
A2
A1
C
L = L1 + L2 + L3 + L4
