WCS 830
WINDLASS CONTROL SWITCH
QUICK DPSeries INSTALLATION AND USER’S MANUAL - REV000A
12
5 - Wiring diagram
WINDLASS
MOTOR
BATTERY
HYDRAULIC
MAGNETIC
SWITCH WCB
(SEE TABLE
ON PAGE 4)
REVERSING
CONTACTOR BOX
T6415-12 (12V)
T6415-24 (24V)
FOOT-OPERATED SWITCHES MOD. 900U E 900D
BLACK
BROWN
BLUE
FUSE
4A (12V)
2A (24V)
BROWN BLACK BLUE
C
A2
A1
L1
L2
L3
L4
L5
RRC R02 RECEIVER
POCKET-SIZE RRC P02
PUSH-BUTTON PANEL RRC H02
PANEL
CHAIN-COUNTER
CHC 1203 - QNC CHC
CONTROLS FOR CONTROL
BOARD WCS 820 - WCS
B - WCS 830
CHAIN-COUNTER
PUSH-BUTTON
PANEL CHC 1103
RRC REMOTE RADIO CONTROLS
TRANSMITTERS
5.0 - Example of connection DP1-DP2 P 300W - 500W
with recommended Quick
®
accessories for the operation of the windlass
MULTI-PURPOSE
PUSH-BUTTON PANEL
HRC 1002
L = L1 + L2 + L3 + L4 + L5
