QUICK DPSeries INSTALLATION AND USER’S MANUAL - REV000A
21
13 - Spare parts
DP1
See exploded drawing on page 16 DP1
CODE DESCRIPTION NUMB. OF PARTS
FVSSGMSDCP05000 OSP DRUM BUSH DP1 2
FVSSMSE04000A00 OSP WINDLASS DRUM DP1 3
FVSSCPBBA050A00 OSP GYPSY COVER DP1 6
FVSSCFDP1000A00 OSP CLUTCH CONE KIT DP1 9
FVSSB0401400A00 OSP GYPSY 1/4" DP1/E1
10
FVSSB0406000A00 OSP GYPSY 6mm DP1/E1
FVSSBDP10C00A00 OSP WINDLASS BASE DP1 SERIES COMP from 16 to 34
FVSSADP10000A00 OSP SHAFT KIT DP1 5 - 7 - 8 from 11 to 15
FVSSADP100D0A00 OSP SHAFT KIT DP1 D 4 - 5 from 11 to 15
FVSSPSCDP100A00 OSP CHAIN PIPE KIT DP1 17 - 19 - 20
FVSSCPSCDP10A00 OSP CHAIN GUIDE COVER KIT DP1 16
FVSSTDP1D001A00 OSP TOP DP1 1/4” D 2 - 3 - 4 - 5 from 9 to 34
FVSSTDP1D006A00 OSP TOP DP1 6mm D
FVSSTDP10001A00 OSP TOP DP1 1/4” 5 - 6 - 7 - 8 from 9 to 34
FVSSTDP10006A00 OSP TOP DP1 6mm 5 - 6 - 7 - 8 from 9 to 34
FVSSLVSDN0000A00 OSP STRAIGHT WINDLASS LEVER 1
DP2
Refer to the exploded drawing on page 17 DP2
CODE DESCRIPTION NUMB. OF PARTS
FVSSBDP20140A00 OSP GYPSY DP2 1/4”
7 - 9
FVSSBDP20516A00 OSP GYPSY DP2 5/16”
FVSSBDP20600A00 OSP GYPSY DP2 6MM
FVSSBDP20800A00 OSP GYPSY DP2 8MM
FVSSBDP2LC00A00 OSP WINDLASS BASE DP2 SERIES COMP
FROM 23 TO 41
FVSSBDP2SC00A00 OSP WINDLASS BASE DP2 SERIES COMP
FVSSCPSCDP20A00 OSP CHAIN GUIDE COVER KIT DP2 23
FVSSTDP2DL01A00 OSP TOP DP2 D L 1/4”
3 - 4 FROM 6 TO 15 17 - 20 FROM
22 TO 41
FVSSTDP2DL05A00 OSP TOP DP2 D L 5/16”
FVSSTDP2DL06A00 OSP TOP DP2 D L 6MM
FVSSTDP2DL08A00 OSP TOP DP2 D L 8MM
FVSSTDP2DS01A00 OSP TOP DP2 D S 1/4”
3 - 4 FROM 6 TO 15 - 19 FROM 21
TO 41
FVSSTDP2DS05A00 OSP TOP DP2 D S 5/16”
FVSSTDP2DS06A00 OSP TOP DP2 D S 6MM
FVSSTDP2DS08A00 OSP TOP DP2 D S 8MM
FVSSTDP20L01A00 OSP TOP DP2 L 1/4”
FROM 5 TO 16 - 20 - FROM 23 TO
41
FVSSTDP20L05A00 OSP TOP DP2 L 5/16”
FVSSTDP20L06A00 OSP TOP DP2 L 6MM
FVSSTDP20L08A00 OSP TOP DP2 L 8MM
FVSSTDP20S01A00 OSP TOP DP2 S 1/4”
FROM 5 TO 15 - 18 - 21 FROM 23
TO 41
FVSSTDP20S05A00 OSP TOP DP2 S 5/16”
FVSSTDP20S06A00 OSP TOP DP2 S 6MM
FVSSTDP20S08A00 OSP TOP DP2 S 8MM
FVSSADP2000LA00 OSP SHAFT KIT DP2 L 11 FROM 13 TO 16 20
FVSSADP2000SA00 OSP SHAFT KIT DP2 S 11 FROM 13 TO 15 18 - 21
FVSSADP200DLA00 OSP SHAFT KIT DP2 D L 11 FROM 13 TO 15 17 - 20 - 22
FVSSADP200DSA00 OSP SHAFT KIT DP2 D S 11 FROM 13 TO 15 19 - 21 - 22
FVSSCFASC000A00 OSP CLUTCH CONE KIT DP2 6 - 8
FVSSCPBBASG0A00 OSP GYPSY COVER DP2 5
FVSSMSE0800XA00 OSP WINDLASS DRUM DP2 4
FVSSPSCDP200A00 OSP CHAIN PIPE KIT DP2 24 - 25 - 29 - 30 - 32
FVSSGMSDCP05000 OSP DRUM BUSH DP2 3
FVSSLVSDN000A00 OSP STRAIGHT WINDLASS LEVER 2
FVSSLVSP00R2A00 OSP CURVED WINDLASS LEVER R2 1
