Quick DP Series User Manual

DP Series
EN
5
1
6
7
4
2
3
8
9
13
14
11
10
15
12
QUICK DPSeries INSTALLATION AND USER’S MANUAL - REV000A
20
12 - List of motorgearbox components
MOTORGEARBOX 1500W DP3
POS NAME
1 GEARBOX FLANGE GASKET TOP TG60
2 WASHER
3 SELF-LOCKING NUT
4 O-RING
5 GEARBOX - QUICK TG70 1500W
6 KEY
7A MOTOR 1500W 12V
7A MOTOR 1500W 24V
8 MOTOR CASING 1000/1400W
9 TERMINAL BOARD GASKET
10 TERMINAL BOARD COVER
11 SCREW
12 SCREW
13 BOTTOM GASKET
14 BOTTOM COVER
15 CABLE GLAND
