QUICK DPSeries INSTALLATION AND USER’S MANUAL - REV000A
8
2 - Supply and equipment
2.0 - Standard supply and material included in the package
• Windlass (top+gearmotor)
• Reversing contactor box for DP1/DP2 300-500W
• Contactor box for DP2/DP3 700-1000W
• Base gasket
• Lever
• Screws for assembly, top/gearmotor
• Installation and user’s manual, Warranty
• Drilling template
2.1 - Tools required for installation
DP1
• Drill with bit: Ø 9 mm (23/64”) and Ø 11 mm (7/16”)
• Hole saw Ø 46 mm (1” 13/16) and Ø 62 mm (2” 7/16)
• Hex wrench: 13 mm
DP2
• Drill with bit: Ø 9 mm (23/64”) and Ø 11 mm (7/16”)
• Hole saw Ø 51 mm (2”) and Ø 64 mm (2” 1/2)
• Hex wrench: 13 mm
DP3
• Drill with bit: Ø 9 mm (23/64”) and Ø 16 mm (5/8”)
• Hole saw: Ø 65 mm (2”9/16) and Ø 67 mm (2”5/8)
• Hex wrench: 13 mm
2.2 - Recommended Quick
®
accessories not included
• Controls for control board (WCS 820 - WCS B - WCS 830)
• Waterproof push-button panel (HRC 1002)
• Foot switch (900)
• Hydraulic-magnetic circuit breaker (WCB)
•Anchor chain counter (CHC 1103 - CHC 1203 - QNC CHC)
•Control system via RRC radio (R02 - P02 - H02)
3 - Introduction
BEFORE USING THE PRODUCT, PLEASE READ THIS USER’S MANUAL CAREFULLY. IF IN DOUBT, PLEASE CONSULT YOUR QUICK® DEALER.
3.0 - Important notes
This manual features Warning and/or Caution symbols that are important for safety.
Please follow the instructions provided.
Warning symbol indicating
dangerous situations.
Caution symbol to prevent direct or
indirect damage to the product.
Thismanualprovidesboatmanufacturersandnauticalequipmentinstallerswithinstructionsonhowtoassemblethespecied
Quick® product and operate it correctly.
