QUICK DPSeries INSTALLATION AND USER’S MANUAL - REV000A
7
1.3 - DP3 Technical Data
MODELS DP3 P - / D
MODEL POWER 700W 1000W
Motor voltage 12V 24V 12V 24V
Maximum instantaneous pull 850 kg (1873.9 lb) 1000 kg (2204.6 lb)
Maximum work load 250 kg (551.1 lb) 300 kg (661.4 lb) 370 kg (815.7 lb) 450 kg (992 lb)
Work load 80 kg (176.4 lb) 100 kg (220.5 lb) 120 kg (264.5 lb) 150 kg (330.7 lb)
Current consumption at work
load
(1)
90 A 55 A 140 A 80 A
Maximum recovery speed
(2)
27.4 m/min (89.9 ft/min) 26.4 m/min (86.6 ft/min) 39.6 m/min (129.9 ft/min) 40.9 m/min (134.2 ft/min)
Recovery speed at work load
(2)
14.4 m/min (47.2 ft/min) 14.8 m/min (48.5 ft/min) 20.4 m/min (66.9 ft/min) 21.4 m/min (70.2 ft/min)
Minimum motor cable cross
section
(3)
25 mm² (AWG3) 10 mm² (AWG7) 35 mm² (AWG2) 16 mm² (AWG5)
Circuit breaker
(4)
50 A 40 A 80 A 50 A
Deck thickness
(5)
25 ÷ 50 mm (63/64” ÷ 1” 31/32)
Weight-model without drum 16.4 Kg (36 lb) 17.4 Kg (38 lb)
Weight-model with drum 18.4 Kg (40 lb) 19.4 Kg (42.2 lb)
MODELS DP3 - / D
MODEL POWER 1500W
Motor voltage 12V 24V
Maximum instantaneous pull 1100 Kg (2425.1 lb)
Maximum work load 470 kg (1036.2 lb) 540 kg (1190.5 lb)
Work load 160 Kg (352.7 lb) 180 kg (396.8 lb)
Current consumption at work load
(1)
155 A 85 A
Maximum recovery speed
(2)
29.2 m/min (95.8 ft/min) 29.7 m/min (97.4 ft/min)
Recovery speed at work load
(2)
16.3 (53.5 ft/min) 19.0 (62.3 ft/min)
Minimum motor cable cross section
(3)
50 mm² (AWG0) 25 mm² (AWG7)
Circuit breaker
(4)
100 A 50 A
Deck thickness
(5)
30 ÷ 50 mm (1” 3/16” ÷ 1” 31/32)
Weight-model without drum 21.3 Kg (46 lb)
Weight-model with drum 23.2 Kg (51 lb)
(1) After an initial period of use.
(2) Measurements taken with a gypsy for 8 mm chain
(3) Minimum recommended value for total length L= <20 m.
Determine the cable cross section according to the length of the wiring.
(4)Withspeciccircuitbreakerfordirectcurrent(DC)anddelayedcircuitbreaker(thermal-magneticorhydraulic-magnetic).
(5) On request, shafts and studs can be supplied for greater deck thicknesses.
GYPSY (*) 8 mm - 5/16” 10 mm- 3/8”
Chain size
8 mm 8 mm 5/16” 5/16” 10mm 3/8”
DIN 766 ISO G4 BBB ISO (P.30) G4
Rope size* 1/2” (12.7 mm) - 9/16” (14.2 mm) - 5/8” (15.8 mm) 5/8” (15.8 mm)
*The values in the table apply to the combination of rope and chain according to the Quick
®
system, we do not guarantee the
correct operation with other anchor-rode types.
1 - Information about the product
