Quick DP Series User Manual

DP Series
EN
DP1 P 3 12 D
QUICK DPSeries INSTALLATION AND USER’S MANUAL - REV000A
5
1 - Information about the product
1.0 - Model code
VOLTAGE (V)
SERIES NAME
POWER
(W)
DRUM (D)
NO DRUM (-)
GEARBOX:
TECHNOPOLYMER (P)
ALUMINIUM (A)
1.1 - DP1 Technical Data
MODELS DP1 P - / D DP1 P HI SPEED
(6)
MODEL POWER 300W 500W 500W
Motor voltage 12V 12V 24V 12V 24V
Maximum instantaneous pull 370 kg (815.7 lb) 660 kg (1455.0 lb) 600 kg (1322.8 lb)
Maximum work load 120 kg (264.5 lb) 200 kg (440.9 lb) 220 kg (485.0 lb) 170 kg (374.8 lb) 200 kg (440.9 lb)
Work load 40 kg (88.2 lb) 65 kg
(143.3 lb)
70 kg
(154.3 lb)
65 kg
(143.3 lb)
70 kg
(154.3 lb)
Current consumption at work load
(1)
60 A 80 A 40 A 100 A 50 A
Maximum recovery speed
(2)
26.3 m/min
(86.3 ft/min)
25.2 m/min
(83.0 ft/min)
39.0 m/min
(128.0 ft/min)
Recovery speed at work load
(2)
22.5 m/min
(73.8 ft/min)
18.5 m/min
(60.7 ft/min)
19.3 m/min
(63.3 ft/min)
28.5 m/min
(93.5 ft/min)
28.0 m/min
(91.8 ft/min)
Minimum motor cable cross section
(3)
16 mm²
(AWG5)
10 mm²
(AWG7)
25 mm²
(AWG3)
10 mm²
(AWG7)
Circuit breaker
(4)
50 A 60 A 40 A 80 A 40 A
Deck thickness
(5)
20 ÷ 30 mm (25/32” ÷ 1” 3/16)
Weight-model without drum 8.3 Kg (18.3 lb)
Weight-model with drum 9.3 Kg (20.5 lb)
(1) After an initial period of use.
(2) Measurements taken with a gypsy for 6 mm chain
(3) Minimum recommended value for total length L= <20 m.
Determine the cable cross section according to the length of the wiring.
(4) Withspeciccircuitbreakerfordirectcurrent(DC)anddelayedcircuitbreaker(thermal-magneticorhydraulic-magnetic).
(5) On request, shafts and studs can be supplied for greater deck thicknesses.
(6) Only on request.
GYPSY (*) 6 mm 1/4”
Chain size
6mm 6mm 1/4”
DIN 766 ISO BBB
(*) For gypsy codes, see the exploded drawing on page 16
BEFORE USING THE WINDLASS READ THESE INSTRUCTIONS CAREFULLY.
IF IN DOUBT, CONTACT YOUR NEAREST “QUICK
®
” DEALER.
QUICK
®
RESERVES THE RIGHT TO MODIFY THE TECHNICAL CHARACTERISTICS OF THE EQUIPMENT AND THE CONTENTS OF THIS MANUAL WITHOUT
PRIOR NOTICE. IN CASE OF DISCORDANCE OR ERRORS IN TRANSLATION BETWEEN THE TRANSLATED VERSION AND THE ORIGINAL TEXT IN THE ITALIAN
LANGUAGE, REFERENCE WILL BE MADE TO THE ITALIAN TEXT.
