QUICK DPSeries INSTALLATION AND USER’S MANUAL - REV000A
6
1 - Information about the product
1.2 - DP2 Technical Data
MODELS DP2 P - / D HI SPEED
(6)
MODEL POWER 300W 500W 500W
Motor voltage 12V 12V 24V 12V 24V
Maximum instantaneous pull 370 kg (815.7 lb) 660 kg (1455.0 lb) 600 kg (1322.8 lb)
Maximum work load 120 kg (264.5 lb) 200 kg (440.9 lb) 220 kg (485.0 lb) 170 kg (374.8 lb) 200 kg (440.9 lb)
Work load 40 kg (88.2 lb) 65 kg (143.3 lb) 70 kg (154.3 lb) 65 kg (143.3 lb) 70 kg (154.3 lb)
Current consumption at work load
(1)
65 A 80 A 40 A 100 A 50 A
Maximum recovery speed
(2)
29.2 (m/min)
(95.8 ft/min)
28.9 (m/min)
(94.8 ft/min)
28.2 (m/min)
(92.5 ft/min)
43.0 (m/min)
(141.1 ft/min)
42.5 (m/min)
(139.4 ft/min)
Recovery speed at work load
(2)
24.4 m/min
(73.8 ft/min)
24.3 m/min
(60.7 ft/min)
24.1 m/min
(63.3 ft/min)
34.5 m/min
(93.5 ft/min)
35 m/min
(91.8 ft/min)
Minimum motor cable cross
section
(3)
16 mm² (AWG5) 10 mm² (AWG7) 25 mm² (AWG3) 10 mm² (AWG7)
Circuit breaker
(4)
50 A 60 A 40 A 80 A 40 A
Deck thickness
(5)
25 ÷ 50 mm (63/64” ÷ 1” 31/32)
Weight-model without drum 9.0 Kg (19.8 lb)
Weight-model with drum 9.8 Kg (21.6 lb)
MODELS DP2 P - / D
MODEL POWER 700W 1000W
Motor voltage 12V 24V 12V 24V
Maximum instantaneous pull 680 kg (1499 lb) 930 kg (2050 lb)
Maximum work load 300 kg (661 lb) 320 kg (705 lb) 420 kg (925 lb) 480 kg (1058 lb)
Work load 100 kg (220 lb) 170 kg (235 lb) 140 kg (308 lb) 160 kg (352 lb)
Current consumption at work load
(1)
95 A 50 A 130 A 75 A
Maximum recovery speed
(2)
22.6 m/min
(74.15 ft/min)
25.3 m/min
(83.0 ft/min)
31.2 m/min
(102.4 ft/min)
30.1 m/min
(98.8 ft/min)
Recovery speed at
work load
(2)
11.6 m/min
(38 ft/min)
14.4 m/min
(47.2 ft/min)
16.5 m/min
(54 ft/min)
19.1 m/min
(62.6 ft/min)
Minimum motor cable cross
section
(3)
25 mm2
(AWG3)
10 mm²
(AWG7)
35 mm²
(AWG3)
16 mm²
(AWG7)
Circuit breaker
(4)
50 A 40 A 80 A 50 A
Deck thickness
(5)
25 ÷ 50 mm (63/64” ÷ 1” 31/32)
Weight-model without drum 12.8 Kg (28.2 lb) 14.2 Kg (31.3 lb)
Weight-model with drum 13.7 Kg (30.2 lb) 15.1 Kg (33.3 lb)
(1) After an initial period of use.
(2) Measurements taken with a gypsy for 6 mm chain
(3) Minimum recommended value for total length L= <20 m.
Determine the cable cross section according to the length of the wiring.
(4)Withspeciccircuitbreakerfordirectcurrent(DC)anddelayedcircuitbreaker(thermal-magneticorhydraulic-magnetic).
(5) On request, shafts and studs can be supplied for greater deck thicknesses.
(6) Only on request.
GYPSY (*) 6 mm 7 mm - 1/4” 8 mm 5/6”
Chain size
6mm 6mm 7 mm 7 mm 1/4” 1/4” 8 mm 8 mm 5/6”
DIN 766 ISO DIN 766 ISO G4 BBB DIN 766 ISO G4
Rope size* 1/2” 1/2” 1/2” 1/2” 1/2”
(*) For gypsy codes, see the exploded drawing on page 17.
