DP Series
EN
QUICK DPSeries INSTALLATION AND USER’S MANUAL - REV000A
22
13 - Spare parts
DP3
Refer to the exploded drawing on page 18
CODE DESCRIPTION NUMB. OF PARTS
FVSSGMSDP300000 OSP DRUM BUSH "SERIES DP3" 2 - 3
FVSSMSE10DP3A00 OSP WINDLASS DRUM 1000W DP3 4
FVSSTDP3D008A00 OSP TOP DP3 D 8MM-5/16”
2 -3 - 4 from 6 to 43
FVSSTDP3D010A00 OSP TOP DP3 D 10MM-3/8”
FVSSADP300D0A00 OSP SHAFT KIT DP3 D from 11 to 14 - 16 - 17 - 18
FVSSLVSP00R2A00 OSP CURVED WINDLASS LEVER R2 1
FVSSCPBBA100A00 OSP GYPSY COVER DP3
5
FVSSTDP30008A00 OSP TOP DP3 8MM-5/16”
from 5 to 17 - from 19 to 43
FVSSTDP30010A00 OSP TOP DP3 10MM-3/8”
FVSSADP30000A00 OSP SHAFT KIT DP3 from 11 to 17
FVSSCPSCDP30A00 OSP CHAIN GUIDE COVER KIT DP3 19
FVSSTCDP3000A00 OSP PRESSURE LEVER KIT DP3 23 - 24 -25
FVSSPSCDP300A00 OSP CHAIN PIPE KIT DP3
20 - 21 - 22 - from 26 to 30
FVSSBDP38516A00 OSP GYPSY DP3 8MM-5/16”
7 - 9
FVSSBDP31038A00 OSP GYPSY DP3 10MM-3/8”
FVSSCFANHC00A00 OSP CLUTCH CONES DP3 6 - 8
FVSSBDP310C00A00 OSP WINDLASS BASE DP3 SERIES COMP
from 19 to 43
MOTORGEARBOX 300/500W DP1 P - DP2 P
See exploded drawing on page 19
CODE DESCRIPTION NUMB. OF PARTS
FVSSMR05TG40B00 OSP GEARBOX 500W WINDLASS QUICK TG40 R1 1 - 2a - 3 - 4 - 12
FVSSMR0540HSB00 OSP GEARBOX 500W WINDLASS QUICK TG40 HS R1 1 - 2b - 3 - 4 - 12
FVSSR0312Q00B00 OSP MOTORGEARBOX 300W 12V QUICK R1
1 - 2a from 3 to 12
FVSSR0512Q00B00 OSP MOTORGEARBOX 500W 12V QUICK R1
FVSSR0512QHSB00 OSP MOTORGEARBOX 500W 12V QUICK HS R1 1 - 2b from 3 to 11
FVSSR0524Q00B00 OSP MOTORGEARBOX 500W 24V QUICK R1 1 - 2a from 3 to 11
FVSSR0524QHSB00 OSP MOTORGEARBOX 500W 24V QUICK HS R1 1 - 2b from 3 to 11
FVSSM0312000A00 OSP WINDLASS MOTOR 300W 12V 3 - 4 from 6a to 11
FVSSM0512000A00 OSP WINDLASS MOTOR 500W 12V 3 - 4 from 6b to 11
FVSSM0512000A00 OSP WINDLASS MOTOR 500W 24V 3 - 4 from 6c to 11
MOTORGEARBOX 700/1000W DP2 P - DP3 P
See exploded drawing on page 19
CODE DESCRIPTION NUMB. OF PARTS
FVSSMR10TG50B00 OSP GEARBOX 1000W QUICK WINDLASS R1 from 1 to 5
FVSSR0712Q00B00 OSP MOTORGEARBOX 700W 12V QUICK R1
from 1 to 14
FVSSR1012Q00B00 OSP MOTORGEARBOX 1000W 12V QUICK R1
FVSSR0724Q00B00 OSP MOTORGEARBOX 700W 24V QUICK R1
FVSSR1024Q00B00 OSP MOTORGEARBOX 1000W 24V QUICK R1
FVSSM0712000A00 OSP WINDLASS MOTOR 700W 12V from 3 - 14 (with 7A)
FVSSM1012000A00 OSP WINDLASS MOTOR 1000W 12V from 3 - 14 (with 7B)
FVSSM0724000A00 OSP WINDLASS MOTOR 700W 24V from 3 - 14 (with 7C)
FVSSM1024000A00 OSP WINDLASS MOTOR 1000W 24V from 3 - 14 (with 7D)
MOTORGEARBOX 1500W DP3
See exploded drawing on page 19
CODE DESCRIPTION NUMB. OF PARTS
FVSSMR15TG70A00 OSP GEARBOX 1500W QUICK WINDLASS from 1 to 5
FVSSR1512Q00A00 OSP MOTORGEARBOX 1500W 12V QUICK
from 1 to 15
FVSSR1524Q00A00 OSP MOTORGEARBOX 1500W 24V QUICK
FVSSM1512000A00 OSP WINDLASS MOTOR 1500W 12V
2-3-4 from 6 to 15
FVSSM1524000A00 OSP WINDLASS MOTOR 1500W 24V
