INSTALLATION AND USE MANUAL QUICK MC² X19 REV002A
7 - Installation procedures
7.3 - Planarity of installation
In the two configurations with base plate (optional) and without base plate, the stabilizer installation must respect
the planarity with the relative tolerance values.
3 mm
3 mm
3 mm
