ENGLISH
12.0 Technical Data
Argon – fixed castor receiver
Castors Fork Front seat Rear seat
height in cm height in cm
24’’ 26’’
3’’ solid 72 mm 43 43-35 43-42
72 mm 44 44-35 44-42
4’’ solid 118 mm 46 46-35 46-42
118 mm 47 47-35 47-42
118 mm 48 48-36 48-42
118 mm 49 49-37 49-42
118 mm 50 50-39 49-42
138 mm 48 48-36 48-42
138 mm 49 48-37 49-42
138 mm 50 48-39 49-42
138 mm 51 48-39 49-42
138 mm 52 48-40 49-42
5’’ solid 118 mm 49 48-37 49-42
118 mm 50 48-39 49-42
118 mm 51 48-39 49-42
138 mm 50 48-39 49-42
138 mm 51 48-39 49-42
138 mm 52 48-40 49-42
138 mm 53 48-41 49-42
6’’ soft 118 mm 51 48-39 49-42
118 mm 52 48-40 49-42
138 mm 51 48-39 49-42
138 mm 52 48-40 49-42
138 mm 53 48-41 49-42
138 mm 54 48-42 49-42
Argon – adjustable castor receiver
Castors Fork Front seat Rear seat
height in cm height in cm
24’’ 26’’
3’’ solid 72 mm 43 43-35 43-42
72 mm 44 44-35 44-42
72 mm 45 45-35 45-42
72 mm 46 46-35 46-42
72 mm 47 47-35 47-42
4’’ solid 118 mm 46 46-35 46-42
118 mm 47 47-35 47-42
118 mm 48 48-36 48-42
118 mm 49 48-37 49-42
118 mm 50 48-39 49-42
118 mm 51 48-39 49-42
118 mm 52 48-40 49-42
118 mm 53 48-41 49-42
5’’ solid 118 mm 49 48-37 49-42
118 mm 50 48-39 49-42
118 mm 51 48-39 49-42
118 mm 53 48-41 49-42
118 mm 54 48-42 49-42
6’’ soft 118 mm 51 48-39 49-42
118 mm 52 48-40 49-42
118 mm 53 48-41 49-42
118 mm 54 48-42 49-42
118 mm 56 48-44 49-44
Seat heights:
The choice of frames, forks and castors, as well as the rear wheel size (24”, 26”) determines the seat heights which can be achie-
ved.
Possible seat heights Important: Measurements without cushions!
Technical Data >>>
Overall width: 24” 26”
With 0° camber SW+20cm SW+20cm
With 3° camber SW+22cm SW+26cm
With 6° camber SW+28cm SW+32cm
With 9° camber SW+34cm SW+38cm
each with narrow-mounted handrims
configuration
Overall length: 107 cm
Overall height: 97 cm
Weight in kg: At least 9.9 kg
Maximum load:
Approved to load of 120 kg
