Filling and Maintenance
A hydraulic steering system rarely needs to be relled aer the system is bled. However, if you ever
need to add uid to the system, refer to the steering manufacturer’s manual for complete
instrucons. The ll point is located on the helm itself, in front of the steering wheel.
REFER TO OWNER’S MANUAL PACKAGE FOR INSTRUCTIONS AND WARRANTY INFORMATION.
Hydraulic Steering
Steering wheel
Helm pump
Hydraulic uid ll
Hydraulic uid lines
Steering cylinder
9. Engine Controls
Your boat comes with a mechanical gear shi/throle control unit, located to the starboard of the
steering wheel, which acvates both the shiing and throle for the engine.
To start the engine, the control unit must be in the NEUTRAL posion. When in neutral, the engine is
running, but the propeller is not spinning. There is a throle only buon that when pressed, will
allow you to operate the throle without the propeller spinning. On the mechanical shi controller,
the buon is located at the center of the throle control, and when moved back to the center
posion, the buon will automacally re-engage the shiing mechanism.
Moving the control lever forward from neutral engages the forward gear and thrust. Moving the
control lever backwards from neutral engages the reverse gear and thrust. The throle lever controls
the RPM of the engine and the speed of the boat.
Power Trim & Tilt
The power trim, located on the side of the gear shi throle handle, allows you to raise and lower
the engine for trailering and launching the boat. It also allows you to adjust the engine to create the
opmum run angle for the boat to achieve best all around performance (fuel consumpon, speed).
REFER TO OWNER’S MANUAL PACKAGE FOR INSTRUCTIONS AND WARRANTY INFORMATION.
10. Emergency Engine Shutdown Switch
Your boat is equipped with an ignion shutdown safety switch built into the engine control. The
ignion shutdown switch incorporates a shut-o switch and a lanyard. Before operang the boat, one
end of the lanyard must be connected to the shut-o switch while the other end is connected to the
operator. If an emergency arises where the engine must be shut down, pull the lanyard cord to
