19. Cockpit Table
On your boat, a cockpit table is available for entertaining. The table and table leg is removable and can
be stored inside the center cockpit hatches. To install the table, rst remove the plasc cover located
in the table base plate. Next, push and lock the table leg into the base plate. Finally, place the table
onto the table leg.
Stored posion
In use posion
Flip seat
Seat rail
Cockpit Table
Table base
Table leg
Table
Table storage
Table leg storage
18. Port Flip Seat (oponal)
As an opon your boat may come equipped with a ip seat, located on the port side of the cockpit.
When not in use, it stores up out of the way in the port deck trail. To use, simply pull the rail located
on the base of the seat out and down.
Port Flip Seat
20. Sun Awning (oponal)
If installed, an oponal sun awning is available to provide protecon from the sun. The sun awning
consists of a rail in the hardtop and a canvas.
Operaon
Within the hardtop rails (port and starboard), there is a pin that holds the awning rail in place. To
extend the sun awning, simply push the pin on both sides and slide the rail out. The pins will re-
engage and lock the rail when fully extended. To install the sun awning canvas, slide the welng
(piping) located on front edge through the sun awning track installed on the hardtop. Next connect
the canvas to the sun awning rail using the zippers on the edge of the canvas. Finally, connect the
straps to the eyelets on the deck.
