Sun Awning
In rough seas, the sun awning should be stored to avoid
damage to the rail and or canvas
Sunshade rail
Pull pin (P&S)
Sunshade canvas
Sunshade straps (P&S)
Deck eyelets (P&S)
21. Canvas (oponal)
As an opon, there is a bimini with frame and a bimini with vinyl panels that fully encloses the cockpit.
Bimini
When not in use, the bimini can be stored in an a posion where it does not interfere with the use of
the boat. In this posion, always make sure that the bimini is secured in the canvas boot. To use the
bimini, remove the canvas boot and rotate the bimini frame forward and secure the canvas to the
hardtop.
Bimini with Enclosure
In addion to the bimini, clear vinyl panels can be installed to enclose the cockpit. Each panel aaches
to the bimini with a zipper and snaps or studs are used to aach to the deck.
NEVER TRAILER THE CANVAS BIMINI, BIMINI WITH
ENCLOSURE, OR SUN AWNING IN THE UPRIGHT POSITION.
The bimini canvas must be secured in the canvas boot with
the rails in the stored posion before trailering.
NEVER OPERATE THE VESSEL WITH THE CANVAS
ENCLOSURE UNLESS THERE IS VENTILATION THROUGHOUT
THE BOAT. The forward and a canvas panels must be
removed to allow air ow through the boat so Carbon
Monoxide cannot accumulate.
