28
Quicksilver 605PH — System & Component Overview and Operaon
13. Diesel Heat (oponal)
The diesel heat system consists of a 3kW heater, a 10L diesel tank providing fuel for the heater, and a
control panel that runs the system.
Operaon
Prior to use, make sure that the diesel tank is full. The 10L diesel tank, located in the starboard bilge,
can be accessed via the forward cockpit oor hatch. To ll the tank, rst remove the strap holding the
tank in place. Next, remove the cap with the fuel pickup and pull the tank out of the boat. ALWAYS
FILL THE TANK OUTSIDE OF THE BOAT. When lled, re-install the cap, and secure the tank in the bilge.
The diesel heater is controlled by a keypad located inside the cabin by the starboard pilaster. The
panel allows for either automac control of a preset temperature, or it allows you to vary the blower
speed and temperature manually. There are two heang ducts throughout the boat. First, there is a
closable outlet located at the dash to defrost the windows for visibility. Next, there is a direconal
outlet located below the helm seats providing heat to the cabin area.
The heater pulls air from two locaons; the rst cold air inlet is located below the helm seat and the
second is an exterior inlet located on the starboard side of the deckhouse. Finally, there is an exhaust
outlet located on the starboard hullside where hot exhaust exits the unit.
REFER TO OWNER’S MANUAL PACKAGE FOR INSTRUCTIONS AND WARRANTY INFORMATION.
DO NOT TURN THE STEERING WHEEL AT THE HELM THAT
DOES NOT HAVE FULL CONTROL OF THE BOAT.
Dual Helm Hydraulic Steering
Steering wheel
Main helm pump
Hydraulic uid lines
Exterior helm pump
Steering cylinder
Vision from the exterior helm staon is limited. Maintain a
lookout as required. Do not operate at planing speeds from
the exterior helm.
Exhaust gas is HOT. Ensure that there is nothing that is
suscepble to heat damage (i.e. ropes, fenders, other
boats) within 200mm of the exhaust outlet.
