Quicksilver 605PH — System & Component Overview and Operaon
27
Cabin engine control
Helm selector switch
Exterior helm engine control
Gear & throle mechanism
Main helm
Exterior helm
Exterior Helm
The steering system is independent of the helm selector switch and will operate at all mes. DO NOT
TURN THE STEERING WHEEL AT THE HELM THAT DOES NOT HAVE FULL CONTROL OF THE BOAT!
Hydraulic Steering
The exterior helm comes with an addional steering helm, steering wheel, and steering hoses that
connects to the base steering system. The operaon of the system is similar, where when you turn the
steering wheel the helm pump forces hydraulic uid through hoses to and from the steering cylinder
which is connected to the ller arm on the engine. Even though the helms are connected, the steering
wheels will not rotate together when one wheel is turned.
Maintenance
A hydraulic steering system rarely needs to be relled aer the system is bled. However, if you ever
need to add uid to the system, refer to the steering manufacturer’s manual for complete instrucons.
REFER TO OWNER’S MANUAL PACKAGE FOR INSTRUCTIONS AND WARRANTY INFORMATION.
