Quicksilver 875SD — System & Component Overview and Operaon
This boat is equipped with an overboard discharge seacock.
Some countries levy severe penales for discharging raw
sewage and solid waste in waters where it is prohibited. Be
aware of local environmental laws, and respect codes of
good pracce. Demonstrang that the macerator is disabled
by locking the system and/or removing the seacock handle
may avoid a ne.
Black Water System
The toilet water pickup valve should always be in the closed
posion when not in use. Failure to do so could result in
ooding, property damage, and/or loss of life.
Toilet water pickup
Pickup to toilet water hose
Toilet
Toilet to holding tank hose
Holding tank with level sender
Holding tank to macerator hose
Macerator
Macerator to overboard discharge hose
holding tank. To see how much uid is in the holding tank, press the momentary switch towards Tank
1.
Macerator
The macerator gives the boat operator the means of discharging the holding tank directly overboard
through a seacock in the boom of the hull. The macerator control is located in the main baery
panel in the starboard baery panel tub labelled “Waste pump 1”. Since direct overboard discharge is
prohibited in many areas, the macerator seacock is normally closed.
To Operate the Macerator:
1. Make sure the macerator seacock is in the open posion.
2. Press and hold the macerator switch located on the main baery panel. The macerator switch
is a momentary switch, which means that it needs to be pressed during operaon.
3. When the tank is empty, stop pressing the macerator switch.
4. Return the macerator seacock to the closed posion.
Overboard discharge
Holding tank to pump out hose
Pumpout deck plate
Holding tank to vent lter hose
Vent lter
Vent lter to tank vent thru hull hose
Tank vent thru hull
Toilet ush switch
