Quicksilver 875SD — System & Component Overview and Operaon
Single Engine Verado L6 Steering
Steering wheel
Tilt helm mechanism
Helm pump
Hydraulic uid lines
Power assist pump
Steering cylinder
Operaon
When turning the steering wheel, the helm pump forces hydraulic uid through hoses to and from the
steering cylinder which is connected to the ller arm on the engine. The cylinder moves the ller arm
to either port and starboard, depending upon the direcon the steering wheel is turned.
Twin Engine L4 / Non-Verado Steering
Steering wheel
Tilt helm mechanism
Helm pump
Hydraulic uid lines
Steering cylinder
Tie bar
Twin Engine Verado L6 Steering
Steering wheel
Tilt helm mechanism
Helm pump
Hydraulic uid lines
Power assist pump
Steering cylinder
Tie bar
