Quincy Compressor 310 - Page 37

QR 310 Quincy Compressor
50214-105, March 2005 36 3501 Wismann Lane, Quincy IL - 62305-3116
TYPICAL UNIT REPTYPICAL UNIT REP
TYPICAL UNIT REPTYPICAL UNIT REP
TYPICAL UNIT REP
AIR PAIR P
AIR PAIR P
AIR P
ARAR
ARAR
AR
TS LISTTS LIST
TS LISTTS LIST
TS LIST
(QR 310 vertical tank - electric motor)
60 gal.
1 114948P200 tank (200 PSI max. working pressure)
1 110425-025 tank drain valve
1 111136-075 ball valve
1 110514-300 pressure gauge
1 110512-003 pressure switch (135-175 PSI)
1 110513-200 pressure relief valve (200 PSI)
2.5 ft. 110515-050 discharge tube (1/2" copper tube to be formed by customer)
2 110948-050 compression fittings
2 h.p.
1 110258B057 drive belt
1 3597-78 motor pulley
n/a motor pulley bushing
1 110945K002 belt guard assembly
115/230v, 1Ø 200v, 3Ø 230/460v, 3Ø
1 4002 8097 124517-002 2 h.p. motor (ODP)
PartPart
PartPart
Part
PartPart
PartPart
Part
PartPart
PartPart
Part
QtyQty
QtyQty
Qty
NumberNumber
NumberNumber
Number
NumberNumber
NumberNumber
Number
NumberNumber
NumberNumber
Number
DescriptionDescription
DescriptionDescription
Description
! Pre-formed discharge tubes are available. Contact factory with model & tank size information.
!
The parts listed here are for
standard QR 310 (up to 175 PSI) units and may or may not be applicable to custom built units. Check with
your local authorized Quincy distributor for parts that can be used for custom built units. Make sure the components you order are rated
within the safe operating limits of your system. If you are doubtful about which components to order, contact your local Quincy distributor.
