Quincy Compressor 310 - Typical Unit Parts List

QR 310 Quincy Compressor
50214-105, March 2005 35 3501 Wismann Lane, Quincy IL - 62305-3116
TYPICAL UNIT REPTYPICAL UNIT REP
TYPICAL UNIT REPTYPICAL UNIT REP
TYPICAL UNIT REP
AIR PAIR P
AIR PAIR P
AIR P
ARAR
ARAR
AR
TS LISTTS LIST
TS LISTTS LIST
TS LIST
(QR 310 simplex - horizontal tank - electric motor)
60 gal. 80 gal.
1 113891-200 113268-200 tank (200 PSI max. working pressure)
1 n/a n/a top plate
1 2713 2713 tank drain valve
1 111136-075 111136-075 ball valve
1 110514-300 110514-300 pressure gauge
1 110512-003 110512-003 pressure switch (135-175 PSI)
1 110513-200 110513-200 pressure relief valve (200 PSI)
2.5 ft. 110515-050 110515-050 discharge tube (1/2" copper tube to be formed by customer)
2 110948-050 110948-050 compression fittings
2 h.p.
1 110258B057 drive belt
1 3597-78 motor pulley
n/a motor pulley bushing
1 110945K002 belt guard assembly
115/230v, 1Ø 200v, 3Ø 230/460v, 3Ø
1 4002 8097 124517-002 2 h.p. motor (ODP)
PartPart
PartPart
Part
PartPart
PartPart
Part
PartPart
PartPart
Part
QtyQty
QtyQty
Qty
NumberNumber
NumberNumber
Number
NumberNumber
NumberNumber
Number
NumberNumber
NumberNumber
Number
DescriptionDescription
DescriptionDescription
Description
The parts listed here are for standard QR 310 (up to 175 PSI) units and may or may not be applicable to custom built units. Check with
your local authorized Quincy distributor for parts that can be used for custom built units. Make sure the components you order are rated
within the safe operating limits of your system. If you are doubtful about which components to order, contact your local Quincy distributor.
PartPart
PartPart
Part
PartPart
PartPart
Part
PartPart
PartPart
Part
QtyQty
QtyQty
Qty
NumberNumber
NumberNumber
Number
NumberNumber
NumberNumber
Number
NumberNumber
NumberNumber
Number
DescriptionDescription
DescriptionDescription
Description
80 gal.
1 113471-200 tank (200 PSI max. working pressure)
2 n/a top plate
1 2713 tank drain valve
1 111136-075 ball valve
1 110514-300 pressure gauge
2 110512-003 pressure switch (135-175 PSI)
1 110513-200 pressure relief valve (200 PSI)
5 ft. 110515-050 discharge tube (1/2" copper tube to be formed by customer)
4 110948-050 compression fittings
2 h.p.
2 110258B057 drive belt
2 3597-78 motor pulley
n/a motor pulley bushing
2 110945K002 belt guard assembly
115/230v, 1Ø 200v, 3Ø 230/460v, 3Ø
2 4002 8097 124517-002 2 h.p. motor (ODP)
(QR 310 duplex - horizontal tank - electric motor)
!
*
* 113281 top plate is used for all QR 310 base mounted electric motor driven units.
** 2298-175 pressure switch is used on standard QR 310 base mounted electric motor driven units.
! Pre-formed discharge tubes are available. Contact factory with model & tank size information.
*
**
**
