9. Technical Data
The voltage on the compressor terminals must not deviate more than 10% of the
nominal voltage.
It is however highly recommended to keep the voltage drop over the supply cables at
nominal current below 5% of the nominal voltage (IEC 60204-1).
If cables are grouped together with other power cables, it may be necessary to use
cables of a larger size than those calculated for the standard operating conditions.
Use the original cable entry. See section Dimension drawings.
To preserve the protection degree of the electric cubicle and to protect its
components from dust from the environment, it is mandatory to use a proper
cable gland when connecting the supply cable to the compressor.
Local regulations remain applicable if they are stricter than the values proposed
below.
Currents are calculated with the full service factor, but we suggest to add 10% due to
over- and under-voltage. Fuses are maximum allowed values for full service factor
and 10% over- and under-voltage.
Caution
Always double check the fuse size versus the calculated cable size. If required,
reduce the fuse size or enlarge the cable size
Cable length should not exceed the maximum length according to IEC60204
table 10.
