Instruction book

2012 2039 28 34

3.7 Inputs menu

Control panel

Text on figure

Reference

Designation

(1)

Scroll keys

(2)

Enter key

(3)

Back key

Menu icon, Inputs

Function

To call up information regarding the actually measured data and the status of some inputs such as the

emergency stop switch.

Procedure

Starting from the main screen (see Main screen),

Move the cursor to the action button Menu and press the Enter key. Following screen appears:
