Section III - Installation
16 Quincy Compressor
•ForQOF7.5:
3.ChangealsothevoltageconnectiononauxiliarytransformerT1.
4.Replacethefuses.
5.Adjusttheoverloadrelaysettings(seesectionSettingsofoverloadrelayandfuses.
Pictographs
Pictographs
Reference Designation
1
Warning:thecompressorstartsandstopsautomatically.Donotperformservice
whenpressurizedandwhenthevoltageison.
Readtheinstructionbook,switchoffthepoweranddepressurizethecompressor
before maintenance or repair.
2
Warning:whenthevoltageison,theunitcanstartandstopautomatically.
3 Warning:rotatingfan.
