Section VIII - Technical data
40 Quincy Compressor
Reference conditions and limitations
Reference conditions
Airinletpressure(absolute) bar 1
Airinletpressure(absolute) psi 14.5
Airinlettemperature ˚C 20
Airinlettemperature ˚F 68
Relative humidity % 0
Workingpressure See section Compressor data.
Limits
Maximumworkingpressure See section Compressor data.
Maximum air inlet temperature ˚C 40
Maximum air inlet temperature ˚F 104
Minimum ambient temperature ˚C 0
Minimum ambient temperature ˚F 32
Compressor data
NOTICE!
All data specified below apply under reference conditions, see section Reference
conditions and limitations.
Compressor type QOF 2 QOF 2 QOF 3 QOF 3
8 bar
116 psi
10 bar
145 psi
8 bar
116 psi
10 bar
145 psi
Maximumworkingpressure(Pack) bar(e) 8 10 8 10
Maximumworkingpressure(Pack) psi(g) 116 145 116 145
Maximumworkingpressure(Full-
Feature)
bar(e) 7.75 9.75 7.75 9.75
Maximumworkingpressure(Full-
Feature)
psi(g) 112 141 112 141
Referenceworkingpressure bar(e) 7 10 7 10
Referenceworkingpressure psi(g) 100 145 100 145
Airtemperatureatoutletvalve
(QOF),approx.
˚C 25 25 25 25
Airtemperatureatoutletvalve
(QOF),approx.
˚F 77 77 77 77
Airtemperatureatoutletvalve
(QOFwithdryer),approx.
˚C 20 20 20 20
Airtemperatureatoutletvalve
(QOFwithdryer),approx.
˚F 68 68 68 68
Motorshaftspeed(50Hz) r/min 1445 1445 2885 2885
Motorshaftspeed(60Hz) r/min 1740 1740 3520 3520
