Section VIII - Technical data
Quincy Compressor 39
QOF 5 QOF 5 QOF 7.5 QOF 7.5
Frequency Voltage
Overload
relay
Maximum
fuse
Overload
relay
Maximum
fuse
IEC
50Hz 200V3~ 17.3A 50A 25.7A 50A
50Hz 230V3~ 15.0A 40A 22.3A 40A
50Hz 400V3~ 8.7A 16A 12.8A 25A
50Hz 400V+N3~ 8.7A 16A 12.8A 25A
UL/CUL
60Hz 200V3~ 16.6A 25/25/30A* 25.2A 40/40/45A*
60Hz 208V -- -- 24.3A 40/40/45A*
60Hz 230V3~ 15.2A 25/25/30A* 24.0A 40/40/45A*
60Hz 460V3~ 7.6A 10/10/15A* 12.0A 20/20/20A*
*:MaximumfusesaccordingHRCII-C,accordingClassK5forunitswithoutrefrigerant
dryerandaccordingClassK5forunitswithrefrigerantdryerrespectively.
Temperature protection and safety valve settings
Temperature shut-down switch settings
Compressor element outlet temperature Opens at Reference
QOF2(8bar/116psi) 70°C(158°F) TDS1
QOF2(10bar/145psi) 80°C(176°F) TSD1
QOF3(8barand10bar/116and145psi) 70°C(158°F) TSD1
QOF5(8barand10bar/116and145psi) 70°C(158°F) TSD1
QOF7.5(8barand10bar/116and145psi) 200°C(392°F) TSD2
Safety valve
Pressure version Set pressure Unit Reference
8barcompressors 8.8 bar(e) SV
116psicompressors 135 psi(g) SV
10barcompressors 11 bar(e) SV
145psicompressors 160 psi(g) SV
