Quintel QS Series MultiServ User Manual

MultiServ Multiband Antennas
QS Series Antenna Installation Guide
INS-AS-004024_E Page 10
Lower arm mount position for all antenna models.
Figure 9: Pole Mount of Lower Mount Assembly (AS-001184)
NOTE:
• Use of a digital inclinometer is recommended for antenna positioning accuracy.
• See above illustration and Table 2 on page 4 for torque settings.
Figure 10: Illustration showing 2 Degree Up Tilt
54 Nm
88 Nm
65 ft lbs
40 ft lbs
