Quinton TM55 User Guide

B-2 Specifications Cardiac Stress Treadmills User Guide
Power Requirements
Listed below are the power requirements for your treadmill
* The nominal voltage range is listed on the serial number
name plate, which can be found on the hood under the
circuit breaker switch.
**Full-load current is computed as described in section
430-24 of the National Electrical Code.
Speed Vs. Weight Range
Nominal Voltage Range
(min - max) / Hertz*
Current Draw
(Amps)
Min. Branch Circuit
Amps
100-120 V, 50/60 Hz 20** 20
200-240 V, 50/60 Hz 10** 10
100
200
300
400
500
1.6 9.68.06.44.83.2
User
Weight
Pounds
Speed (mph)
Performance Envelope 115V or 230V Operation
250
Pounds
6.7 mph
4.8 mph
