Installation with a COMBI
Follow the steps below to install the Scale Control Plus with a Quooker COMBI.
The ‘Q’ on the top of the tank is the on / o switch.
B
1. Turning o the tank
Turn o the tank. Leave the plug in the
socket. Open the boiling water tap and
let the water become cold. Also open the
cold water tap. Close the inlet combination
rst, and then the tap. Then turn o the
mains cold water supply.
2. Removing the copper pipe
Remove the copper pipe, including the
nuts and clamping rings, between the
T-piece and inlet combination.
3. Mounting the inlet combination
Mount the push-t using the insert on the
inlet combination. Then connect one of
the two plastic tubes (B) to the push-t.
4. Mounting the bracket
Screw the bracket onto the kitchen
cabinet wall using the two long screws
provided.
3 4
1 2
COLD
COLD
D
2
