Page 9
This is how the RaceChip looks in its  nal installed position. We will now explain step-by-step how to install it.
RaceChip Ultimate Connect
RaceChip Ultimate Connect
Setup illustration
Common Rail
connection socket
Installed RaceChip
RaceChip wiring harness
cable with disconnected
series plug
Common Rail
connection socket
