Page 11
This image shows the connection that is relevant for the installation in your vehicle.
It may be the case that the engine
in your vehicle is not longitudinal,
as shown in step 2, but rather
transverse. In this case you must
apply the steps of the installation
instructions to the type of engine
you have. The installation steps
remain the same.
Please check your e-mail inbox.
If available, we will send you
additional vehicle images for the
installation via email.
Step 2 of 9
Connecting to sensors
Transverse engine
Longitudinal engine
Common Rail connection socket
Common Rail connection socket
