Page #12 background imageLoading...
Page #12 background image
REFERENCE
Display
The 2-line 16-character LCD displays menu selections and measurement results.
Characters positioned at the left side of the display have special meaning:
> in Setup indicates a parameter choice. Press select to chose the item.
For dose measurements:
? indicates dose-sensor signal was outside calibrated range .
> indicates high-sensitivity mode measurement.
[ indicates low -sensitivity mode measurement.
] indicates cumulative (zero-corrected) dose is negative.
For kV measurements:
W means Wait. The kV system is unable to process another exposure while W is displayed.
A indicates automatic filtration compensation is enabled.
D indicates default filtration will be used: 2.5 mm Aluminum for the diagnostic sensor.
30μm Molybdenum for the Mammography sensor
M indicates a user-selected filter (other than 2.5 mm Al).
T indicates a Tungsten/Rhodium anode/filter
S indicates a Tungsten/Silver anode/filter
In the lower right corner of the display:
C indicates a dose sensor (ion chamber or diode)
K indicates dose from the Accu-kV diode
The kV display may be configured in Setup. The following table shows the selections for each of the four
locations on the display. Default
values are underlined.
Location Measurement
Upper Left kVp
kV practical kV
reduced
kV avg
Upper
Right
mAs
width
pulses
width
ms
mA
Lower
Left
conv dose
width
pulses
width
ms
mA
Lower*
Right
width ms
kV diode
dose rate
rel
dose rate
pulses
* Readout not present if Lower Left is Conv Dose in kV
12
