Setup–Menu Functions
Pressing select at the main menu display
Change or SELECT
setup
enters Setup. The following information and options are provided in this mode::
! Serial No. and firmware Version
This manual applies to version 6.
! Pressure and temperature
Values used for ion-chamber compensation. Prefixed with Std if measured not selected.
! SELECT restores setup defaults.
Restores all items in Setup to default values. Default values are shown as Default
in the following
descriptions.
See detailed instructions on page 8
! Mode SELECT
Parameter Choices Accu-Pro Accu-Dose Accu-kV
Pressure Measured
/Std 101.3 kPa X X
Temperature Measured
/Std 22 deg C X X
Len/area suffix On(*cm or *cm2)/Off
XX
High sensitivity
1
On/Off XX
Radiation units Roentgens
/Grays/Coulombs X X
Auto shutdown On
(30 min)/Off X X X
Time units Seconds/Minutes
/Hours X X X
Mammo anode/filter Mo/Mo,
W/Ag, W/Rh X X
DAC output kV
/mA/Rel. intensity/dose rate X X
1
The Accu-Pro measures the background zero when you select a dose mode. If high sensitivity is set to
off, the system will make a quick coarse zero measurement. Some fluctuations will be observed in dose
rate mode and dose accumulate may exhibit drifting. If high sensitivity is set to on, the system will make
a fine zero measurement which takes 3 to 5 seconds. The dose rate will fluctuate much less and the
dose accumulate drift will be greatly reduced. It is recommended that high sensitivity mode is enabled for
most dose measurements.
! Function SELECT
Add/Remove functions from the main menu. See Page 17 for a list of functions
! kV disp(lay) SELECT
See table on page 12
! Intrinsic filt(ration) SELECT
Selects the filtration used to compute kV in the diagnostic range. Auto enables automatic calculation
based on beam hardness.
Auto
, Cu (32 steps from 0 to 0.695 mm), Al (32 steps from 0 to 23 mm).
19
