In the mode of FM, when any range is chosen, the mode of manual tuning will search
in one of ranges.
When selected, the numbers 1, 2, 3, and 4 can be displayed directly above the LCD
In the mode of SW, press “SUB BAND” to choose from 11 receiving band ranges.
Tip: When the time is displayed, long press “SUB BAND” to set MW manual tuning
range and numeric tuning range while switching between FM numeric tuning range.
For details, please refer to 7.3.1.
There are different ranges because every potentiometer has an error, and it’s difficult
to realize consistency between all radios.
The frequencies beyond the range can be displayed but cannot be received.
There is a seamless connection between manual tuning and numeric tuning. When
rotating the potentiometer with “ ”, it will automatically switch to manual tuning.
VHF/AIR/WB doesn’t support manual tuning, so it will switch to corresponding
frequency after calculation with the algorithm through the potentiometer.
When switching frequencies using shuttle and buttons, it will automatically switch to
numeric tuning.
7.3.3: In the mode of numeric tuning, switch between SW meter waves:
SW receiving frequency range: 3.2-21.95MHZ
Numeric tuning: in the mode of SW, press “ ” to show 11 SW meter waves:
3.20MHZ, 4.75MHZ, 5.60MHZ, 7.35MHZ, 9.90MHZ, 12.10MHZ,
13.87MHZ, 15.80MHZ, 17.90MHZ, 19.10MHZ, 21.85MH
press “ ” to quickly switch and choose.
SW1:3.2-4.1MHZ
SW2:4.7-5.6MHZ
SW5:9.2-10MHZ
SW6:11.4-12.2MHZ
SW7:13.5-14.3MHZ
SW8:15-15.9MHZ
SW9:17.4-17.9MHZ
SW10:18.9-19.7MHZ
SW11:21.4-21.9MHZ
RF320
11
