RM-111 Operations Manual

Speciﬁ cations

Electronic Relay Speciﬁ cation

Type: Mercury wetted reed relay

Resistance: .020 ohms typical, .050 ohms maximum

Imax: 1 amp AC RMS

Vmax: 630 volts AC RMS (relay clamped at 680V)

VA-max Switch: 10 VA inductive

Operate Time: 2 mS maximum

Release Time: 2 mS maximum

Offset Time: 0.5 mS maximum

Dielectric Withstand: 2.5 kV to any other part of the unit
