Radian RM-111 - 2 Specifications; Physical; Electrical; Environmental

RM-111 Operations Manual
Specifi cations
Specifi cations
8
2.0 Specifi cations
2.1 Physical
Length: 190mm (7.5")
Width: 105mm (4.0")
Height: 33mm (1.25") approx.
Weight: .85 lbs approx.
Case Construction: Flame resistant ABS plastic with
polycarbonate label / keypad.
Keypad good for 1 million cycles
2.2 Electrical
Power: 9 volt battery or 9-12 volt AC adapter
Power Consumption: 171 mW typical, 1.150 W maximum
2.3 Environmental
Temperature: -20º to 70º C (-4º to 158º F) normal
operating conditions
Relative Humidity: 0 - 95%
Shock and Vibration: Any which is nondestructive
Water Resistance: Unit is splash proof, but it is not air
tight
Orientation: Any, unless using the RM-1R electronic/mechanical relay
accessory.When using the electronic option, the arrow in the
relay box must remain in the upward position with repect to
the horizon.
