RM-111 Operations Manual
Keypad Conventions
Keypad Conventions
12
3.0 RM-111 Keypad Conventions
14
13
12
11
10
9
8
7
6
4321
15
1. PORT A Input
2. PORT B Input
3. PORT C Input
4. PORT D Input/Output
5. Serial Port
6. Pickup
7. 9-12V DC Input Jack
8. Cancel
9. Enter
10. Up/Down Arrow Keys
11. Left/Right, Yes/No Arrows keys
12. Shift
13. Alphanumeric Keypad
14. On/Off
15. LCD Intensity
16. 4 Line 16 Character per Line LCD
5
16
