RM-111 Operations Manual
Pulse Constants
Pulse Constants
20.0 Pulse Constants and Kh values for the RM-111
(*SC-10, *SC-10v, *SC-30, *A-7, *IB-10 and the RM-16)
Note: When using an RM-16 the position of the Pulse Constant switch located on the front panel,
will be the multiplier for the following pulse constants and Kh values. The chart below is applicable
for the 1,000 switch setting.
RM 150A 0.00001 1.0
RM 200A 0.00002 2.0
SC-30 HI 0.00001 1.0
SC-30LO 0.0001 1.0
NON-AUTORANGING STANDARDS
AUTORANGING STANDARDS
DEVICE PULSE Kh
& TAPS CONSTANTS VALUE
(SC-10,RM-16)
DEVICE PULSE Kh
& TAPS CONSTANTS VALUE
1A 120V 0.00012 0.12
5A 120V 0.0006 0.60
12.5A 120V 0.0015 1.50
15A 120V 0.0018 1.80
50A 120V 0.006 6.00
1A 240V 0.00024 0.24
5A 240V 0.0012 1.20
12.5 240V 0.003 3.00
15A 240V 0.0036 3.60
50A 240V 0.012 12.00
1A 480V 0.00048 0.48
5A 480V 0.0024 2.40
12.5A 480V 0.006 6.00
15A 480V 0.0072 7.20
50A 480V 0.024 24.00
86
* See page 96
