Application 5
parameters to run a standards test. The arrow keys are used to move the cursor throughout this
screen. Enter the appropriate value for each parameter:
Name - Enter a test setup name on the fi rst line by typing over the current text (16 characters
maximum).
PriKh – Enter the primary reference standard(s) Kh value.
Kh – Enter the DUT Kh value.
#Pulse – Enter the number of pulses for the reference standard(s) to output before stopping the
test.
Time* – not applicable for this test
Test by* - Select PULSE
Type – Select M. Gating (mechanical gating) for the gating method
#Standards – Enter the number of reference standards that will be used. In this application, select
one.
Mode – If more than one reference standard is used, the user must choose between single-phase or
polyphase modes of operation.
Ref Type – This defi nes the reference standard output pull-up value. Select Radian (150 ohm).
Other is 1000 ohm.
Input A** – Select either DUT or REF
SER#1 – Enter a serial number for standard 1, if applicable.
SER#2 – Enter a serial number for standard 2, if applicable.
SER#3 – Enter a serial number for standard 2, if applicable.
* The “Test By:” parameter input allows the user to select the type of test – TIME, PULSE,
MANUAL, or ENERGY. If ENERGY is selected, the “ Time:” parameter input dynamically
changed to “Energy:”. This allows a test to be stopped after a pre-set amount of energy has been
accumulated by the DUT
46
