Example 3 – Set Manufacturer ID, Unique ID, version and device information
Example
This example sets
• Manufacturer ID (M_ID) to “RAD” = 0x2448 (Radiocrafts).
Note! To get your own Manufacturer ID, register a 3-letter code with DLMS, then use 5-bit
ASCII representation.
• Unique ID (U_ID) to 0x12345678,
• Version (VER) to 0x01
• Device type (DEV) to “Gas Meter”. Please see Configuration parameter table for different
device types.
Command
Hex
Response
Comment/Note
(Wake up)
0xFF
Wake up the UART interface
Enter
0x00
‘>’
Enter CONFIG mode.
Wait for ‘>’ prompt.
‘M’
0x4D
‘>’
M-command entered.
Wait for ‘>’ prompt.
0x19
(none)
Address M_ID1
0x24
(none)
Value M_ID1
0x1A
(none)
Address M_ID2
0x48
(none)
Value M_ID2
0x1B
(none)
Address U_ID1
0x12
(none)
Value U_ID1
0x1C
(none)
Address U_ID2
0x34
(none)
Value U_ID2
0x1D
(none)
Address U_ID3
0x56
(none)
Value U_ID3
0x1E
(none)
Address U_ID4
0x78
(none)
Value U_ID4
0x1F
(none)
Address VER
0x01
(none)
Value VER
0x20
(none)
Address DEV
0x03
(none)
Value DEV
0xFF
‘>’
Exit M-command.
Wait for ‘>’ prompt.
‘Z’
0x5A
(none)
Exit CONFIG mode.
Module returns to SLEEP state
