RC1180-MPC1/RC1701HP-MPC1 User Manual (rev. 1.1)
RC1180-MPC1
USER MANUAL RC1701HP-MPC1
Example 6 Example message Configuration message (OTA123, step 1), RC1701HP-MPC1
Example
The below shows the configuration dump message send from an RC1701HP-
MPC1 module when OTA123 is enabled and the config pin is asserted.
L
C
LL_HEADER
APP DATA NO TPL_HEAD
M_MID
M_MID
M_UID
M_UID
M_UID
M_UID
M_VER
M_DEV
CI
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
Field
Hex
Comment/Note
L
0xB3
Length
C
0x44
SND-NR
M_MID
0x24 0x48
Manufacturer ID. MSB first
M_UID
0x78 0x56 0x34 0x12
Unique ID. MSB first
M_VER
0x01
Version
M_DEV
0x02
Electricity meter
CI
0xAA
CI field for the Application Layer.
No header.
DATA
03 05 01 11 02 00 00 00
FF 00 00 00 01 01 80 80
CC 00 00 01 00 00 17 00
00 48 24 12 34 56 78 01
00 00 00 00 00 00 00 00
00 00 03 03 7A 00 06 66
05 08 00 01 05 00 00 00
00 00 00 44 06 02 00 00
FF FF FF FF FF FF FF FF
FF FF FF FF FF FF FF FF
00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00
93 93 93 93 73 03 5E 03
0D 07 06 07 10 10 10 10
0E 0E 0E 0E 10 10 10 10
01 00 00 00 09 9A 8C 9A
3A B0 A0 B0 30 2F 2E 2C
00 52 43 31 37 30 31 48
50 2D 4D 50 43 31 2C 31
2E 31 30 2C 31 2E 30 30
20 20 20 20 20 20 20 20
20
Values for addr 0x00-0x07
Values for addr 0x08-0x0F
Note: the actual data record start after CI=AA (bold). There is no header in this message.
